F145 Electric pivoting fixed pool lift with ridgid seat for pool access of disabled people Max load 140kg

F145 Electric pivoting fixed pool lift with ridgid seat for pool access of disabled people Max load 140kg

€6474.72

The F145 Electric Pivoting Fixed Pool Lift is a robust and reliable accessibility solution designed to provide safe, comfortable, and efficient pool access for individuals with disabilities or reduced mobility. Equipped with an electric lifting and pivoting mechanism, it ensures smooth, controlled, and secure movement into and out of the pool, significantly improving user comfort and reducing operator effort. This model features a rigid, ergonomically designed seat that provides enhanced stability, support, and safety during transfers. Manufactured from corrosion-resistant, high-strength materials, the F145 is suitable for both indoor and outdoor pools, including public swimming pools, leisure centres, rehabilitation facilities, hotels, and private installations. Its fixed anchoring system ensures maximum structural integrity and long-term reliability. The 140 kg maximum load capacity meets modern accessibility and safety standards, making it ideal for everyday use in demanding environments.

BluePulse Advanced Swimming Pool Engineering Limited provides full installation, configuration, operator training, and both warranty and post-warranty service for all fixed and mobile pool lifts.

Contact us at webshop@bluepulse.ie for product selection support, technical advice, and on-site accessibility assessment.

  • Symbol: 200102004
  • Delivery time: up to 14 days

♿ F145 – Semi-Portable Fixed Pool Lift (High Pole Version)

Medical Device (EU 2017/745 – Class I)

The F145 High Pole Version is a semi-portable fixed pool lift designed for safe water access for users with reduced mobility.
The system combines fixed anchoring points installed on the pool deck with a removable seat and wheeled trolley, allowing transport of the user between the pool and changing rooms.

The lift can be anchored using three certified installation methods:

  1. External fixing plate with dowels,

  2. In-ground concrete block (60 × 60 × 60 cm),

  3. Recessed disappearing ground socket.
    This flexibility makes the F145 suitable for a wide range of pool facilities.

⚙️ Technical Specifications

  • Maximum capacity: 140 kg

  • Maximum travel: 1350 mm

  • Lifting/lowering time (with user): 20 seconds

  • Rotation: 360°

  • Unit weight: 66 kg

  • Battery: 24 V removable battery

  • Average autonomy: approx. 50 working cycles

🔧 Control & Safety Systems

  • IPX06 spiral-cable handset for up/down controls (usable from inside the water)

  • Emergency stop button

  • Removable battery + charger

  • 2-point safety belt (standard)

  • Stainless steel frame for submerged parts

  • Galvanised and powder-coated structural components for corrosion resistance

🪑 Comfort & Functional Features

  • Retractable leg support

  • Adjustable armrests

  • Wheeled trolley for user transport

  • Fully removable seat system

  • Rotation 360° for easy positioning over pool edge

📦 Optional Accessories

  • Different arm lengths

  • Three certified anchoring systems (plate / concrete block / recessed socket)

  • Protective actuator cover

📍 Typical Applications

  • Public swimming pools

  • Rehabilitation and hydrotherapy centres

  • Hotel, wellness & spa environments

  • Facilities requiring semi-portable certified medical lifting equipment

🏛️ Certifications & Compliance

  • EU Regulation 2017/745 – Medical Devices (Class I), DM 321258/R

  • Directive 2006/42/EC – Machinery Directive

  • Directive 2004/108/EC – EMC Electromagnetic Compatibility



Symbol: 200102004
