♻️ BADU EasyFit 12 – Three-Phase Pool Circulation Pump (400/230 V, 50 Hz)

The BADU EasyFit 12 is a three-phase self-priming circulation pump designed for small to medium-sized swimming pools in residential or light-commercial environments.
It combines quiet performance, long service life, and excellent hydraulic efficiency, making it an ideal choice for professional filtration systems.
Built with corrosion-resistant materials, it is suitable for chlorinated and mild salt-water pools (up to 0.5 % salt concentration).

✅ Key Features

• Three-phase 400/230 V (Y/Δ) supply – ensures stable and efficient operation for larger installations.

• Self-priming design – allows flexible pump placement up to 2 m above or 3 m below the water level.

• Low-noise asynchronous motor with full electrical isolation from water for maximum safety.

• Durable corrosion-resistant housing – ideal for long-term use.

• Transparent strainer lid – simplifies inspection and maintenance.

• Salt-water compatible up to 0.5 % (≈ 5 g/L).

• Integrated thermal overload protection for safe operation.

• Compact, modular design for easy installation and retrofit applications.

⚙️ Technical Specifications

• Model: BADU EasyFit 12

• Power supply: 3~ 400/230 V (Y/Δ) / 50 Hz

• Input power (P₁): ≈ 0.75 kW

• Output power (P₂): ≈ 0.50 kW

• Flow rate: ≈ 12 m³/h

• Connections: Ø 50 mm suction / Ø 50 mm discharge

• Self-priming lift: up to 2 m

• Max water temperature: 60 °C

• Max salt concentration: 0.5 % (≈ 5 g/L)

• Recommended pool volume: up to ≈ 48 m³ (depending on system configuration)

📍 Typical Applications

• Private and commercial swimming pools

• Compact and medium filtration systems

• Salt-water and chlorinated pools

• Retrofit and pump replacement projects
