Triton Neo Side Clear Pro, 762mm-30''

Triton Neo Side Clear Pro, 762mm-30''

€1749.00

The Triton Neo Side Clear Pro 762 mm (30") is a premium large-capacity side-mount sand filter designed for high-performance water filtration in large private pools, commercial pools, leisure centres, and aquatic facilities. Featuring advanced Clear Pro Technology, this model achieves ultra-fine filtration far superior to traditional sand filters—capturing much smaller particles and providing dramatically clearer water. The heavy-duty composite tank offers exceptional durability, corrosion resistance, and stable operation under demanding conditions. The 30" (762 mm) diameter provides a high filtration surface area, ensuring efficient flow rates, low pressure loss, and compatibility with multiple filter media options, including silica sand, glass media, and AFM®.

BluePulse Advanced Swimming Pool Engineering Limited provides full installation, system configuration, media replacement, and both warranty and post-warranty service for all commercial and residential filtration systems.

Contact us at webshop@bluepulse.ie for technical guidance and support in selecting the optimal Triton Neo filter for your pool.

  • Symbol: 110102103
  • Availability: Available
  • Delivery time: up to 14 days

♻️ Triton Neo Side Clear Pro – 762 mm / 30’’

High-Performance Side-Mount Sand Filter

The Triton Neo Side Clear Pro 30" is a high-quality side-mount swimming pool sand filter designed to offer superior water clarity, long-term durability, and efficient hydraulic performance.
Equipped with ClearPro Technology, it filters particles up to four times smaller than standard sand filters — providing visibly clearer and more polished water.

Built with a reinforced composite tank, UV-resistant materials, and a heavy-duty side-mount multiport valve, this model is ideal for medium-size commercial pools, high-end residential pools, wellness facilities, and aquatic centers where reliable filtration is essential.

✅ Key Features

  • ClearPro Technology for ultra-fine filtration

  • 762 mm (30") diameter – excellent flow and filtration surface

  • Side-mount multiport valve for easy control and backwashing

  • One-piece composite tank – corrosion-proof and UV-resistant

  • Low pressure drop for improved pump efficiency

  • Compatible with sand, glass media, and advanced filtration media

  • Long-life internal components for maximum reliability

  • Large service hatch for easy inspection and maintenance

  • Quiet and stable hydraulic performance

  • Ideal for premium residential and medium-size commercial installations

⚙️ Technical Specifications

  • Model: Triton Neo Side Clear Pro 762 mm

  • Filter diameter: 762 mm / 30’’

  • Mounting type: Side-mount multiport valve

  • Material: Fiberglass-reinforced composite

  • Filtration media: Sand / Glass / Advanced media

  • Max operating pressure: ~3.5 bar (typical)

  • Flow rate: Suitable for medium-volume systems

  • Connections: Commercial-grade unions

  • Recommended pool volume: ~60–200 m³ (depending on turnover rate & hydraulics)

📍 Typical Applications

  • Medium-size commercial swimming pools

  • Hotels & boutique resorts

  • Wellness centres & spas

  • Sports and recreation facilities

  • Premium private pools

  • Aquatic and therapy pools

Size: 762mm-30''
Color: Blue
Symbol: 110102103
Weight 29.8 kg
Warranties: 12 years tank warranty
Connection IN: 2 in.
Connection OUT: 2 in.
Filter area: 0.45 m²
Filter capacity at 30m³/h/m²: 13.2 m³/h
Filter capacity at 50m³/h/m² (backwash capacity): 22 m³/h
Gravel: 75 kg
Sand: 200 kg
AFM Grade 1: 126 kg
AFM Grade 2: 105 kg
