♻️ BADU EasyFit Eco VS – Variable‑Speed Universal Pool Circulation Pump

The BADU EasyFit Eco VS is a highly flexible, variable‑speed circulation pump designed for swimming pool filtration systems where installation ease, energy efficiency, and retrofit compatibility are key. It combines the universal mounting and connection adaptability of the EasyFit range with the energy‑saving capabilities of a multi‑speed permanent‑magnet motor. BlueCube Direct+2speck.nl+2

✅ Key Features

• Variable‑speed permanent‑magnet motor – provides significant energy savings by matching pump output to demand rather than running at full power constantly. esta-poolshop.de+1

• Universal installation compatibility – includes multiple connection sets and adjustable pump feet so the pump can replace many older designs without major plumbing changes. speck.nl+1

• Self‑priming up to 3 m above or below water level, increasing installation flexibility. POOL Total - Ihr Poolshop in Minden!+1

• Durable materials and full electrical isolation – motor shaft does not contact pool water; the housing is corrosion resistant and suitable for salt‑water up to ~0.5% salinity. profluid GmbH+1

• Programmable speed and control interface – allows up to three preset speeds plus external control input for optimized filtration and cost savings. yapool.de+1

⚙️ Technical Specifications

• Model: BADU EasyFit Eco VS

• Voltage / Phase: 1~ 230 V (single‑phase) – typical variant. DIV-Pumpen.de

• Flow range: Up to approx. 32 m³/h at ~8 m head. profluid GmbH+1

• Power consumption (P₁): approx. 0.03‑1.40 kW (depending on speed) DIV-Pumpen.de+1

• Power output (P₂): up to approx. 1.10 kW profluid GmbH

• Connections (standard): Ø63 mm suction / Ø63 mm discharge (with optional sets) DIV-Pumpen.de+1

• Recommended pool volume: approx. 30–90 m³ (for the 230 V variant) DIV-Pumpen.de

• Max water temperature: 60 °C approx. yapool.de

• Max salt concentration: up to ~0.5% (≈ 5 g/L) for standard version yapool.de+1

???? Typical Applications

• Residential swimming pools (especially where retrofit or replacement is required)

• Pools using salt‑water or chlorinated systems

• Filter systems where variable speed control can deliver major energy savings

• Installations where ease of replacing the old pump without complex plumbing rework is desired
