♻️ BADU Delta 9/3 Y – High-Efficiency Pool Circulation Pump (400/230 V)

Three-Phase Premium Pump for Residential & Light Commercial Pools

The BADU Delta 9/3 Y is a compact, energy-efficient three-phase circulation pump designed for residential and semi-commercial swimming pools requiring reliable water turnover, low noise, and long-term durability.
Equipped with BADU’s optimized hydraulic design, it delivers strong filtration performance while maintaining excellent energy efficiency and quiet operation.

Built with a corrosion-resistant thermoplastic housing, glass-fibre reinforced impeller, and stainless-steel internal components, the BADU Delta 9/3 Y ensures long operational life even in saltwater installations.
Its integrated large-capacity prefilter provides superior debris retention and stable water flow, making it ideal for continuous-duty circulation systems.

✅ Key Features

• Three-phase 400/230 V motor for enhanced efficiency and stability

• Optimized hydraulic performance for excellent flow and reduced power usage

• Quiet, low-vibration operation

• Large built-in prefilter for improved protection and water clarity

• Corrosion-resistant design, suitable for saltwater and chlorinated pools

• Self-priming system ensures consistent and reliable operation

• Thermal overload protection for safe operation

• Durable thermoplastic construction with reinforced impeller

• Easy service access with transparent prefilter lid

⚙️ Technical Specifications

• Model: BADU Delta 9/3 Y

• Power supply: 400/230 V (three-phase), 50 Hz

• Motor output: approx. 0.75–1.1 kW

• Flow rate: approx. 15–18 m³/h (installation dependent)

• Connections: Ø63 mm union fittings

• Prefilter: Large debris basket with transparent lid

• Pump housing: Thermoplastic, corrosion-resistant

• Impeller: Glass-fibre reinforced composite

• Protection class: IP55 with thermal protection

• Installation: Suitable for indoor or sheltered outdoor installation

📍 Typical Applications

• Residential swimming pools

• Light commercial pools, guesthouses, small hotels

• Auxiliary filtration and circulation systems

• Saltwater pools and spa systems
